Parallel LINQ (PLINQ) with Visual Studio 2010/2012 - Perf testing



On the last day of May I wrote about how to calculate prime numbers with LINQ in C#. To close that post I said that I’d use the PrimeNumbers delegate to evaluate PLINQ (Parallel LINQ) and measure the performance gains when the same calculation is done in parallel instead of in a sequential fashion.

PLINQ is LINQ executed in Parallel, that is, using as much processing power as you have in your current computer.

If you have a computer with 2 processor cores like a dual core processor you'll get your Language Integrated Query operators do the work in parallel using both cores.

Using "only" LINQ you won't get as much performance because the standard Language Integrated Query operators won't parallelize your code. That means your code will run in a serial fashion not taking advantage of all your available processor cores.

There are lots of PLINQ query operators capable of executing your code using well known parallel patterns.

After this brief introduction to PLINQ let’s get to the code.

As promised, today I show the performance gains when the PrimeNumbers delegate is run in 2 cores (parallel) instead of only 1 core (sequential).

Here’s the delegate code:

Func<int, IEnumerable<int>> PrimeNumbers = max =>
from i in Enumerable.Range(2, max - 1)
where Enumerable.Range(2, i - 2).All(j => i % j != 0)
select i;

To make it a candidate to parallelization we must just call the AsParallel() extension method on the data to enable parallelization for the query:

Func<int, IEnumerable<int>> PrimeNumbers = max =>
from i in Enumerable.Range(2, max - 1).AsParallel()
where Enumerable.Range(2, i - 2).All(j => i % j != 0)
select i;

I set up a simple test to measure the time elapsed when using the two possible ways of calling the delegate function, that is, sequentially in one core and parallelized in my two available cores (I have an Intel Pentium Dual Core E2180 @ 2.00 GHz / 2.00 GHz).

Let’s calculate the prime numbers that are less than 50000 sequentially and in parallel:

IEnumerable<int> result = PrimeNumbers(50000);
Stopwatch  stopWatch = new Stopwatch();

stopWatch.Start();

foreach(int i in result)
{
    Console.WriteLine(i);
}

stopWatch.Stop();

// Write time elapsed
Console.WriteLine("Time elapsed: {0}", stopWatch.Elapsed);

Now the results:

1 core
Time elapsed: 00:00:06.0252929

2 cores
Time elapsed: 00:00:03.2988351

8 cores*
Time elapsed: 00:00:00.8143775

* read the Update addendum bellow

When running in parallel using the #2 cores, the result was great - almost half the time it took to run the app in a sequential fashion, that is, in only #1 core.

The whole work gets divided into two worker threads/tasks as shown in Figure 1:

Prime Numbers PLINQ Parallel Stacks Window ( #2 cores )
Figure 1 - The Parallel Stacks window in Visual Studio 2010 ( #2 cores )

You can see that each thread is responsible for a range of values (data is partitioned among available cores). Thread 1 is evaluating the value 32983 and Thread 3 is evaluating 33073. This all occurs synchronously.

If I had a computer with 4 cores, the work would be divided into 4 threads/tasks and so on. If the time kept decreasing I’d achieve 1.5 seconds to run the app. Fantastic, isn’t it?

The new Microsoft Visual Studio 2010 (currently in Beta 2) comes with great debugging tooling for parallel applications as for example the Parallel Stacks shown in Figure 1 and the Parallel Tasks window shown in Figure 2:

Prime Numbers PLINQ Parallel Tasks Window ( #2 cores )
Figure 2 - The Parallel Tasks window in Visual Studio 2010 ( #2 cores )

This post gives you a rapid view of PLINQ and how it can leverage the power of you current and future hardware.

The future as foreseen by hardware industry specialists is a multicore future. So why not get ready to it right now? You certainly can with PLINQ. It abstracts all the low level code to get parallel and let’s you focus on what’s important: your business domain.

If you want to go deep using PLINQ, I advise you to read Patterns for Parallel Programming: Understanding and Applying Parallel Patterns with the .NET Framework 4 by Stephen Toub.

Updated on February 15, 2013

Running this same sample app on a Intel Core i7-3720QM 2.6GHz quad-core processor (with #4 cores and #8 threads) this is the result:

Time elapsed: 00:00:00.8143775

This is on a par with the #1 core and #2 cores tests shown above. The work is being divided "almost" evenly by 8 if we compare with the first benchmark ( only #1 core ).

00:00:06.0252929 / 8 = 0.7525

Of course there’s been lots of improvements between these different processor generations. The software algorithms used to parallelize the work have also been improved (now I’m running on Visual Studio 2012 with .NET 4.5). Both hardware/software specs are higher now. Nonetheless these numbers give a good insight about the performance gains both in terms of hardware and software. Software developers like me have many reasons to celebrate! Party smile

Prime Numbers PLINQ Parallel Tasks Window ( #8 threads )Figure 3 - The Parallel Stacks window in Visual Studio 2012 ( #8 threads )

If I take out the .AsParallel() operator, the program runs on a single core and the time increases substantially:

Time elapsed: 00:00:03.4362160

If compared with the #4 cores benchmark above, we have:

00:00:03.4362160 / 4 = 0.8575

0.8575 – 0.8143 = 0.0432 (no difference at all)

Note: this faster processor running on a single core has a performance equivalent to the old Intel #2 core processor. Pretty interesting.
